What are the installation methods for casters?

There are various installation methods for casters, and the following are some common installation methods and their applicable scenarios:

1、 Conventional installation method

Fixed installation

Characteristic: The casters are fixed in one position and cannot rotate or move.

Applicable scenarios: Suitable for scenarios that require stable support from casters, such as fixed brackets for some heavy equipment.

Universal installation

Features: The casters can rotate 360 degrees, providing all-round mobility flexibility.

Applicable scenarios: Suitable for scenarios that require frequent changes in movement direction or comprehensive flexibility, such as hospital beds, mobile devices, etc.

Screw installation

Features: The casters are fixed to the equipment or object through a screw rod, installed firmly, and suitable for heavier loads.

Installation steps: It is necessary to pre-set matching threaded holes at the installation site, and then screw the casters in through the screw.

Applicable scenarios: Suitable for heavy equipment or scenarios that require high load-bearing capacity.

2、 Other installation methods

Insertion pole installation

Features: The casters are equipped with insertion rods, which can be directly inserted into the installation holes at the bottom of the equipment and then fastened with nuts or other fixing devices.

Installation requirements: High requirements are placed on the size and accuracy of the installation holes.

Applicable scenarios: Commonly used for devices with specific structures, with quick and convenient installation.

Tablet installation

Features: The flat plate on the casters is directly attached to the installation surface at the bottom of the device, and fixed with bolts.

Installation steps: Simple and convenient, with strong versatility.

Applicable scenarios: Suitable for most devices that require caster support.

3、 Combination installation method

In practical applications, in order to meet the needs of different devices, it is often necessary to combine and install different types of casters. Here are some common combinations:

Installation combination of 3 universal wheels

Features: Suitable for handling barrel shaped and small equipment, with good maneuverability that surpasses the 4-wheel installation method with the same specifications.

Installation combination of 1 universal wheel and 2 directional wheels

Features: Suitable for short distance handling of low center of gravity, medium and light equipment, with good directional control and economy.

Installation combination of 2 universal wheels and 2 directional wheels

Features: Conventional assembly method, suitable for long-distance transportation of heavy equipment, economical and durable. According to the different pushing or pulling methods, the configuration of the front and rear wheels can be flexibly adjusted.

Installation combination of 4 directional wheels

Features: Suitable for long straight-line distance handling of heavy equipment, but not suitable for working surfaces with slopes.

Installation combination of 2 universal brake wheels and 2 directional wheels

Features: Suitable for long and short distances and sloping roads, the braking function improves safety.

Installation combination of 4 universal wheels

Features: Suitable for short distance handling of heavy equipment, with excellent directionality, often used for factory workshop turnover work.

Installation combination of 4 universal wheels and 2 directional wheels

Features: Suitable for long-distance handling of heavy equipment and extended countertops, with good maneuverability, suitable for horizontal contact surfaces.

4、 Installation precautions

The casters should be installed horizontally to ensure stability and load-bearing capacity.

Universal casters should be installed with their rotation axis perpendicular to ensure rotational flexibility.

Select appropriate connecting components such as screws, nuts, and washers, and tighten them correctly to avoid loosening.

When installing brake casters, avoid screwing in the brake while in operation to prevent damage and deformation of the brake.

In summary, there are various installation methods for casters, and the appropriate installation method should be selected according to the specific needs and usage scenarios of the equipment. During the installation process, pay attention to following the correct installation steps and precautions to ensure the stability and safety of the casters.
